VectorForge — Licença Vitalícia (Windows e Linux)
O VectorForge é um programa CAD 3D totalmente paramétrico que compra uma única vez. 49,99 $, sem subscrição, sem conta, sem cloud, atualizações gratuitas para sempre. Windows 10/11 e Linux em x86-64 e ARM64 (funciona num Raspberry Pi).
Esboce e aplique restrições. Linhas, retângulos, polígonos, arcos, círculos, engrenagens evolventes. Um resolvedor de 15 restrições que pode arrastar: horizontal, vertical, comprimento, ângulo, paralelo, perpendicular, distância, raio, alinhado, tangente, no círculo, igual, fixo, colinear, ancorado. As restrições horizontais e verticais são inferidas à medida que desenha; as restrições conflituantes ficam vermelhas para que saiba qual alterar.
Modele com sólidos reais. Extrusão, bolso, revolução, ranhura, varredura, loft (reto ou ao longo de um guia), casca, chanfro, arredondamento, espelhamento, padrões lineares e rotacionais, padrões de padrões, fusão / corte / intersecção booleana, num núcleo manifold. As roscas são geometria helicoidal real: furos roscados e cabeças métricas ISO e roscas para tubos NPT de acordo com a norma ASME B1.20.1, com conicidade de 1:16. Escreva M8x1.25 12 ou 1/2 NPT e está lá.
Crie montagens. Oito tipos de juntas inferidos a partir da geometria em que clica: rotativa, deslizante, cilíndrica, esférica, planar, de parafuso, fixa e de engrenagem. Acione e limite as juntas, depois agarre qualquer peça e o resolvedor de cinemática inversa move toda a cadeia em tempo real, na GPU para montagens grandes.
Simule enquanto projeta. Análise de elementos finitos dentro do modelador: fixe faces, aplique forças em N, g ou lb, adicione gravidade, escolha PLA, nylon, ABS, PC ou alumínio e veja o deslocamento e a tensão de von Mises na peça, sinalizados em relação ao limite de escoamento e recalculados a cada edição.
Importe e exporte. STEP e STL entram como sólidos editáveis que pode extrudar, roscar e aplicar operações booleanas. Exportação STL por peça ou pelo modelo completo. Os projetos são pequenos ficheiros legíveis por humanos no seu disco.
Rápido no que é seu. Visualizador e seleção por GPU, todos os resolvedores em todos os núcleos da CPU, uma cache de recursos que reconstrói apenas o que mudou. Um conjunto completo de engrenagens gira a 60 FPS em hardware com oito anos.
A licença. Uma pessoa, em todas as máquinas de que é proprietária, para sempre. Tudo o que projeta é seu. Garantia de devolução do dinheiro de 14 dias. Link de download e chave por e-mail em minutos.
What you are buying
The parts that decide whether a CAD package can do real mechanical work, all included.
Lines, rectangles, polygons, arcs, circles, involute gears and construction geometry. Fifteen constraint types, under-constrained sketches flagged, conflicts in red. Grab a point and the sketch moves exactly as far as the constraints allow.
Pad, pocket, revolve, groove, sweep, loft, shell, chamfer, fillet, mirror, linear and rotational pattern, boolean fuse / cut / intersect. On a manifold boolean kernel that does not leave slivers.
Tapped holes, threaded bosses and bores with true helical geometry. ISO metric to M64, NPT pipe threads to ASME B1.20.1 with the 1:16 taper. They print, they pattern, they survive booleans.
Revolute, slider, cylindrical, ball, planar, screw, fixed and gear joints inferred straight from geometry. Drive, limit, lock, ground. Drag a part and inverse kinematics moves the chain.
Fix faces, apply forces in N, g or lb, add gravity, pick a material. Displacement and von Mises stress on the part, max stress against yield, re-solved on every edit. GPU compute where there is GL 4.3, every CPU core otherwise.
Stable geometry references mean a fillet placed on copy 2 of a pattern stays on copy 2. Change anything, anywhere, and the rest rebuilds. Nothing is ever baked.
Imported bodies are editable: pad off their faces, pocket, thread, chamfer, fillet, shell, pattern and boolean them like anything drawn here. Export STL per part or whole model.
GPU viewport with GPU picking, every solver multithreaded, a feature cache that only rebuilds what changed. Real time on a laptop; usable on a Raspberry Pi.
Windows 10/11 as a zip, Linux as a single AppImage (Debian 12 / glibc 2.36 or newer, including Raspberry Pi OS and Armbian). No installer, no admin rights.
No account, no license server, no telemetry, no cloud. A small human-readable project file you can diff, back up and keep forever.
A key for every constraint, right-click menus everywhere, values typed in plain English: M6 10, 500g, 1/2 NPT 15. Backspace repeats. Esc gets you out.
Twelve automated suites run every build: geometry, threads, NPT, sweeps, lofts, shells, assemblies, FEA against beam theory, STEP round-trips, and every bug a customer has sent us.
Yes. $49.99 once. No subscription, no maintenance fee, no paid upgrade tier, no "pro" version hiding the good features. Every point release and every major version is included, for as long as VectorForge exists.
Yes. Download the full program and use it free for 14 days on Windows 10/11, Linux x86-64 or Linux ARM64. No account, no card, no email. If it earns its place, buy a license for $49.99 and keep it for good. Every recording on this page is also an unedited capture of the real software, and the release notes show what gets fixed and how fast. If you buy and change your mind within 14 days, email us for a full refund.
64-bit Windows 10 or 11, and 64-bit Linux down to Debian 12 (glibc 2.36 or newer) on x86-64 and ARM64, so Raspberry Pi 4/5, Rock Pi and similar boards work. It needs OpenGL 3.1; the optional GPU compute solvers use OpenGL 4.3 where available and fall back to every CPU core where not. There is no macOS build.
Capable enough to build a rocket nozzle with a pipe-threaded manifold, a six-axis arm or a meshing gearbox in a single file. Sketches with a 15-constraint solver; pad, pocket, revolve, groove, sweep, loft, shell, chamfer, fillet, mirror, patterns and booleans on a manifold kernel; metric and NPT threads as real geometry; a full parametric timeline. It is not a surfacing or sheet-metal package.
Eight joint types: revolute, slider, cylindrical, ball, planar, screw, fixed and gear. Joints are inferred from the geometry you click: a boss in a bore is a pin, two edges a slider. Drive and limit joints, lock them, ground a part, then grab anything and the inverse-kinematics solver moves the chain in real time, on the GPU for large assemblies.
Linear static analysis: fix faces, apply forces in N, g or lb, turn on gravity, choose PLA, PA-6, PA-12, ABS, PC, 6061 aluminum or type your own E, Poisson's ratio and yield. You get displacement and von Mises stress on the part, the maximum flagged red against yield, re-solved on every edit. It is built for "will this bracket hold?" during design. It is not nonlinear, thermal, dynamic or contact simulation.
Real. A tapped hole or threaded boss is true helical geometry swept along the pitch and combined through the boolean kernel. ISO metric from the coarse-pitch table or any pitch you type; NPT pipe threads to ASME B1.20.1 with the 1:16 taper, external and internal, 1/16" to 12". They export to STL, voxelise for the simulation, and survive patterns and fillets.
It imports STEP and STL as editable solid bodies and exports STL, per part or whole model. Your editable history is saved in the native .vforge format, a small human-readable text file. Formats added later are included in your license.
The viewport and picking run on the GPU. The boolean kernel, sketch solver, mesher, FEA and assembly solvers run across every CPU thread (and on GPU compute where available). A feature cache rebuilds only what changed. Nothing waits on a server. That is why a whole gear train turns at 60 FPS on eight-year-old hardware, and why it is usable on a Raspberry Pi.
No. There is no login, no license server to reach, no telemetry and no file sync. Your models stay on your drive and the software works fully offline, forever.
All of your own: desktop, laptop, the workstation at the shop, the Pi on the bench. The only rule is one license per person; you can't give copies to others.
Set the quantity on the product page and check out once. Each license is for one person on all of their machines. You receive one key per license by email.
$49.99. Windows and Linux, x86-64 and ARM64. Every future version included. 14-day refund if it isn't for you.
